Series KM - 25mm Diameter Ball Nut

  • Series KM 25 mm Diameter Ball Nut
  • Series KM 25 mm Diameter Ball Nut Dimension Drawing
Click image to enlarge
Series KM - 25mm Diameter Ball Nut
Patented adjustable anti-backlash design
(when used with required mounting blocks)
Made of steel, repeatability of < 0.01 mm
Accuracy of < 0.1 mm, Wipers avail.
Flange or base mounting options
Click here for CAD models
Configure Your Part
Select Options then Click “Add to Quote”
Part Number:
Quantity
Add To Quote

Ball Screw Nuts
Ø Item-No.  spindle pitch  dynamic load [N]  static load [N]
25 213700 0005  5 38 50 5,100 12,600
213700 0010  10 38 50 5,100 12,600
213700 0020  20 38 70 3,570 8,800
